POWERFUL - 19.2kW Charging

ADVANCED - ISO 15118 Plug & Charge

CONVENIENT - Cable Management System

PROFITABLE - Generate Advertising Revenue Using 8 Inch High-Definition Screen

SMART - Dynamic Load Balancing

Input/Output Power Rating & Current>> 12kW (240V AC*50A)

Input/Output Voltage>> 208V±15%; 240V±15%, 60Hz

Network Type>> L1/N+PE, L1/L2/PE

Input Cord>> Hardwired

Connector Type>> SAE J1772, 25ft (7.5m)

Ground Fault Detection>> 20mA CCID

Protection>> Overcurrent, Overvoltage, Undervoltage, Integrated Surge Protection

Power Measurement Accuracy>> Full Scale

Enclosure Rating>> NEMA 4

Operating Temperature Range>> -40°F ~+131°F (-40°C ~+55°C)

Storage Temperature Range>> -40°F ~+185°F (-40°C ~+85 °C)

Mounting>> Wall Or Floor Using A Pedestal

Dimensions>> (H×W×D) 336×187×85mm

Status Indication>> LED/APP/Touch Screen (5 Inch LCD, 800*480)

User Interface>> RedE Enterprise App

Connectivity>> Bluetooth, Wi-Fi, Ethernet, 4G, CAN, RS485

Communication Protocols>> OCPP 1.6J (Can Be Upgraded To OCPP 2.0.1 Later)

User Authentication APP, RFID Card

Card Reader>> ISO 15693, ISO 14443, NFC

Software Update>> OTA

In stock

Freight shipping
